Power Q-2200 Set - Leg Treatment Set Size L

The device supports various types and sizes of cuffs, which can be purchased separately. Choose the cuff that allows targeted treatment of the desired area.

Arm, leg, and waist cuffs each have a special design for effective treatment of their respective areas. Up to three four-chamber cuffs can be connected simultaneously.

The arm cuff is especially useful for post-mastectomy arm lymphoedema treatment. Leg cuffs are available in variants reaching below the knee and mid-thigh in various sizes. Waist cuffs come in short pants or belt form, ideal for treating the abdomen and hips.

Upper limb treatment

Arm lymphoedema usually affects one side, so typically only a single arm cuff is needed. For restoring athletic muscle, consider using two arm cuffs to treat both arms simultaneously. The arm cuff has a velcro strap that can attach under the opposite underarm.

Arm cuff

Before purchase, measure your arm circumference at the wrist, forearm, and below the underarm. Choose the correct size based on these measurements. The cuff is available in M and L sizes.

M-L arm cuff sizes: the green line and the lowercase number indicate length in cm, the red line and the bold number indicate circumference in cm.

Lower limb treatment

Before selecting a cuff, measure the circumference of the lower limb at the ankle, calf, kneecap, and thigh base. The thigh-length leg cuff is available in M-L sizes; if it does not fit, a zipper extender is also available.

Thigh-length leg cuff

This cuff is ideal for treating lower leg lymphoedema, varicose veins, and post-thrombosis conditions. Athletes can use it for muscle regeneration. Depending on whether one or both legs are affected, purchase one cuff or a pair. Sizes can be increased with extensions if standard sizes do not fit.

M-L thigh cuff sizes: the green line and the highlighted number indicate length in cm, the red line and the bold number indicate circumference in cm.

Waist and hip-abdomen treatment

For treating the thigh, hip, buttock, and upper abdomen, choose from shorts or belt cuffs.

These cuffs are necessary when lymphoedema extends to the thigh and trunk also needs treatment. They are also used in beauty treatments post-cellulite, cellulite, and post-liposuction fat breakdown.

The shorts cuff provides more effective treatment by enclosing the entire thigh and buttocks. The belt cuff resembles a mini skirt, so the inner thigh and lower buttock are not treated.

Shorts cuff

The shorts cuff provides 360° treatment on the upper thigh, buttocks area, and lower abdomen. Ideal for thigh-hip lymphoedema treatment. Three rows of zippers allow size adjustment (smallest, middle, largest). Also excellent for beauty care, such as cellulite and groove bag treatments. The cuff contains a built-in airhose; no separate airhose is needed.

Belt cuff

The belt cuff is used where the thigh cuff ends (from mid-thigh upwards) and secures with velcro. It is less effective than the shorts cuff but more affordable. Suitable for lymphoedema and beauty care (cellulite). The belt cuff requires a separate airhose. To select the correct size, measure your abdomen (just under the navel) and hip circumference.

P = shorts cuff - M-L belt waist cuff sizes: the green line and highlighted number indicate length in cm; the red line and bold number indicate circumference in cm.

Cuff combinations

In some cases, combining cuffs, using multiple cuffs simultaneously, may be necessary.

However, do not use more than one cuff simultaneously in cases of heart failure, post-infarction status, cardiomyopathy, or uncontrolled high blood pressure.

The Power Q-2200 allows adjustment of key treatment parameters, making it ideal for mild to moderate lymphoedema and varicose vein maintenance therapy at home, post-thrombosis condition treatment, and more.

The device supports leg (M-L), arm (M-L), and waist (M-L shorts) cuffs. To select the correct size, refer to the size chart and measure your circumference!

Up to three cuffs (each with 4 chambers) can be connected simultaneously. Pressure is equal in all chambers.

The device offers 4 programs (A, B, C, D). B is the gentlest, followed by A, then D, with C being the strongest. Be patient: start with programs B or A and switch to stronger settings only if necessary. All programs are suitable for athlete muscle regeneration or post-stroke rehabilitation.

Programs inflate from bottom to top: first, the lowest chamber inflates, then the next. Each inflated chamber applies pressure to the tissue beneath, "squeezing out" edema (lymph). Treatment time can be set to 15 or 30 minutes; the device stops automatically when time elapses.

Treatment guide

Follow your doctor’s or therapist’s instructions.

General guidelines: Lymphatic massage aims to improve blood and lymph circulation without high pressure – excessive pressure is harmful. Use program A or B for initial treatments. Set pressure at 40 or 60 mmHg. Start with 15 minutes; monitor results and increase to 30 minutes if needed. It is better to perform multiple 30-minute sessions than occasional long ones. Limit daily treatment to 120 minutes. Be patient – allow 3-4 sessions before assessing changes; avoid frequent adjustments.

Steps to set the device

1. Set treatment duration: press the "T" button to choose 15 or 30 minutes.

2. Enable/disable airchambers: by default, every chamber inflates. To exclude certain chambers, tap the corresponding leg symbols; illuminated LEDs indicate active chambers.

3. Set treatment pressure: use the "+" and "-" buttons. The selected value shows on the display. Each active chamber inflates at the same pressure.

4. Select program: choose from 4 intensity programs. From gentlest to strongest: B, A, D, C. Program C provides the strongest treatment fastest but may not suit everyone. Use program B if no special instructions.

5-6. Set intervals: for C and D programs, pressing the interval button repeatedly sets 5, 10, or 30-second breaks between cycles.

6. START/STOP button: press to start treatment with selected settings; press again to stop.

Risks of incorrect treatment

A pressure of 40-60 mmHg is sufficient to support lymphatic and venous circulation. International medical studies recommend this range. Higher pressure may cause microinjuries, leading to tissue hardening over time. Excessively strong treatments can worsen your condition – avoid high pressure!

Exercise caution with heart disease, heart failure, cardiomyopathy, or post-infarction status. Never exceed 40-50 mmHg and use only one cuff at a time; multiple cuffs can overload circulation and cause heart problems.

Avoid direct treatment of malignant tumor tissue as it may promote spread. However, in thyroid cancer, it is safe to treat your leg.

Expected results

Regular use of the Power Q-2200 can lead to:

• Reduced swelling: effectively reduces limb edema.
• Pain relief: alleviates discomfort from swelling and venous insufficiency.
• Improved mobility: increases joint range of motion by reducing swelling and stiffness.
• Complication prevention: reduces risk of venous ulcers and thrombosis.

Treatment duration and frequency

Duration and frequency depend on condition and individual factors. Typically, one session lasts 20-60 minutes and may be repeated once or multiple times daily as needed. Regular use over several weeks is recommended for best results. Consult a lymphatic therapist for a personalized plan.

Risks and contraindications

Machine-assisted compression therapy may be unsuitable in some cases or require caution and lower pressure.

Contraindications:

• Severe peripheral arterial disease (PAD): increased pressure may harm significantly impaired arterial circulation.
• Severe heart failure: fluid shifts require limited area and lower pressure.
• Active deep vein thrombosis (DVT): compression can dislodge clots; strictly contraindicated.
• Acute skin infections (e.g., erysipelas): massage may spread pathogens and worsen inflammation.
